Specification:
Overall specifications: length 8505X width 1700x height 1250 (MM)
Substrate conveying direction: to left to right (above the working surface)
Roller pitch: 70~80mm
Width of conveying chamber: 536mm
Working height: 900mm soil 25mm
Body structure: Material PVC (Japanese Taslon transparent board) Thickness 10~ 12t/mm.
Tank structure: Material PVC (Japanese Taslon transparent board) 12t/mm Maximum allowable operating temperature: 50°C
Conveying roller: equipped with UPEψ35 guide wheel conveying material UPE specification ψ12mm
Transmission gear: Helical gear 13T UPE (slave)/PVDF (master)
Drive shaft: material SUS304 specification ψ16mm half moon type
Drive motor: brushless motor (Taiwan Taiwan)
Power supply: 380V ± 10V, 50Hz, AC three-phase, 36KW
Exhaust air volume: 30m³/MIN The exhaust air is arranged on the upper side of the machine body, and the wire duct is arranged on the upper side of the rear side of the machine body.
Pure water consumption: 15L/MIN
Driven shaft: material SUS304 specification φ12MM
Transmission roller: PE material, one-time molding Specification φ12 X 36MM
Circulation pipe: the pure water section is a stagnant water pipe
Whole machine control: man-machine interface and PLC control, with water saving, power saving, plate blocking, alarm, counting functions, the tank is equipped with low liquid level shutdown protection function
Electrical components: famous brand products from Japan, France, Taiwan, etc.
Pressure gauge: with pressure detection, differential pressure alarm function
Nozzle: Easy-to-detach plastic nozzle
Pump: Yiweiqi, Grundfos pump
Air pump: Taiwan product (with frequency conversion speed regulation)
Specification of total inlet pipe: DG25 (outer diameter is φ32MM)
Specification of total drain pipe: DG80 (outer diameter is φ90MM)
Exhaust pipe specification: DG150 (outer diameter is φ160MM)
